£316.22 £263.52

iiyama ProLite T1731SR-W5 17" 1280 x 1024pixels Single-touch White touch screen monitor

£316.22 £263.52
In stock
SKU

T1731SR-W5

Need help ordering? Call 0208 200 2000

17" 5-wire resistive touchscreen, 1280 x 1024, 1000:1, 5:4, 5ms, IP54
ProLite T1731SR-W5 is based on 5 wire resistive touch technology. The price / performance ratio is ideal for the budget conscious user while quality and performance are certainly not compromised. The display inputs include both analogue and digital (VGA, HDMI and DisplayPort) with touchscreen connectivity via USB offering great flexibility. A solid and steady base supports the touchscreen with an adjustable stand offering full 90-degree angles. The ProLite T1731SR-W5 can be used in a variety of environments, especially recommended for shops, restaurants and industrial purposes. Available in black and white.
More Information
SKU T1731SR-W5
EAN 4948570116027
Specification
Display
HDCPYes
Screen shapeFlat
Display number of colours16.78 million colours
Native aspect ratio5:4
Display technologyTN
Viewing angle, horizontal170°
Viewing angle, vertical160°
Pixel pitch0.264 x 0.264 mm
Horizontal scan range31 - 80 kHz
Vertical scan range50 - 75 Hz
Aspect ratio5:4
Separate H/V syncYes
Display resolution1280 x 1024 pixels
Response time5 ms
Display diagonal43.2 cm (17")
Contrast ratio (typical)1000:1
TouchscreenYes
Display diagonal (metric)43 cm
Touch technologySingle-touch
Touchscreen technologyResistive
Display brightness200 cd/m²
Anti-glare surfaceYes
Audio
Built-in speaker(s)Yes
RMS rated power2 W
Performance
Built-in speaker(s)Yes
RMS rated power2 W
Megapixel (approx.)1.3 MP
Card reader integratedNo
Built-in cameraNo
AMD FreeSyncNo
NVIDIA G-SYNCNo
Windows operating systems supportedYes
Linux operating systems supportedYes
Management features
Number of OSD languages7
On Screen Display (OSD) languagesSimplified Chinese, German, English, Spanish, French, Italian, Japanese
Plug and PlayYes
Multimedia
Number of speakers2
Built-in speaker(s)Yes
RMS rated power2 W
Megapixel (approx.)1.3 MP
Built-in cameraNo
Design
CertificationCB, CE, TÜV-Bauart, VCCI, GOST
Product colourWhite
International Protection (IP) codeIP54
Camera
Megapixel (approx.)1.3 MP
Built-in cameraNo
Ports & interfaces
VGA (D-Sub) ports quantity1
HDMI ports quantity1
DisplayPorts quantity1
HDCPYes
Audio input1
HDMIYes
Card reader integratedNo
Technical details
Height (without stand)34.2 cm
Depth (without stand)20.1 cm
Width (without stand)38.7 cm
Cable lock slotYes
HDMIYes
Display viewable area (HxV)338 x 270 mm
Card reader integratedNo
Product colourWhite
Power supply typeAC
TouchscreenYes
Software
Windows operating systems supportedYes
Linux operating systems supportedYes
Ergonomics
Wall mountableYes
VESA mountingYes
Cable lock slotYes
Panel mounting interface100 x 100 mm
LED indicatorsYes
Tilt angle range-5 - 90°
Number of OSD languages7
On Screen Display (OSD) languagesSimplified Chinese, German, English, Spanish, French, Italian, Japanese
Plug and PlayYes
Cable lock slot typeKensington
TiltableYes
Power
Power supply typeAC
AC input voltage100 - 240 V
AC input frequency50 / 60 Hz
Power consumption (standby)2 W
Power consumption (typical)20 W
Energy efficiency scaleA to G
Energy efficiency class (SDR)E
Energy consumption (SDR) per 1000 hours13 kWh
Power managementYes
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)20 - 80%
Storage relative humidity (H-H)10 - 90%
Packaging content
Quick start guideYes
Cables includedAC, Audio (3.5mm), DisplayPort, HDMI, USB
Weight & dimensions
Height (without stand)34.2 cm
Depth (without stand)20.1 cm
Width (without stand)38.7 cm
Weight (without stand)5.8 kg
Indication
LED indicatorsYes
Packaging data
Quick start guideYes
Cables includedAC, Audio (3.5mm), DisplayPort, HDMI, USB
Logistics data
Harmonized System (HS) code85285210
Other features
Height (without stand)34.2 cm
Depth (without stand)20.1 cm
Width (without stand)38.7 cm
Quick start guideYes
HDMIYes
Energy efficiency scaleA to G
Power supply typeAC
Display viewable area (HxV)338 x 270 mm
Power managementYes
TouchscreenYes
Full HDNo
Certificates
CertificationCB, CE, TÜV-Bauart, VCCI, GOST
Manufacturer iiyama
PDF Url https://objects.icecat.biz/objects/mm
