| Specification |
| Display |
|---|
| Display | IPS | | Screen shape | Flat | | Display number of colours | 16.78 million colours | | Native aspect ratio | 16:9 | | HD type | Full HD | | Display technology | LED | | Viewing angle, horizontal | 178° | | Viewing angle, vertical | 178° | | Pixel pitch | 0.2652 x 0.2652 mm | | Horizontal scan range | 30 - 80 kHz | | Vertical scan range | 56 - 75 Hz | | Aspect ratio | 16:9 | | Separate H/V sync | Yes | | Display resolution | 1920 x 1080 pixels | | Response time | 5 ms | | Display diagonal | 58.4 cm (23") | | Contrast ratio (typical) | 1000:1 | | Touchscreen | Yes | | Number of simultaneous touchpoints | 10 | | Panel type | IPS | | Display diagonal (metric) | 58.4 cm | | Touch technology | Multi-touch | | Touchscreen technology | Projected capacitive system | | LED backlight | Yes | | Display brightness | 215 cd/m² | | Ports & interfaces |
|---|
| USB 2.0 ports quantity | 5 | | DVI port | Yes | | VGA (D-Sub) ports quantity | 1 | | DVI-D ports quantity | 1 | | HDMI ports quantity | 1 | | PC Audio in | Yes | | HDMI | Yes | | Audio |
|---|
| Built-in speaker(s) | Yes | | RMS rated power | 4 W | | Performance |
|---|
| Built-in speaker(s) | Yes | | RMS rated power | 4 W | | Built-in camera | No | | AMD FreeSync | No | | NVIDIA G-SYNC | No | | Windows operating systems supported | Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64 | | Management features |
|---|
| Number of OSD languages | 9 | | On Screen Display (OSD) languages | Simplified Chinese, German, English, Spanish, French, Italian, Japanese, Portuguese, Russian | | Plug and Play | Yes | | Multimedia |
|---|
| Number of speakers | 2 | | Built-in speaker(s) | Yes | | RMS rated power | 4 W | | Built-in camera | No | | Design |
|---|
| Certification | CE, TÜV-Bauart, VCCI, PSE, CU | | Product colour | Black | | Camera |
|---|
| Built-in camera | No | | Technical details |
|---|
| Width (without stand) | 56.1 cm | | Cable lock slot | Yes | | HDMI | Yes | | Product colour | Black | | Power supply type | AC | | USB 2.0 ports quantity | 5 | | Weight (with stand) | 6.3 kg | | Touchscreen | Yes | | Number of simultaneous touchpoints | 10 | | Software |
|---|
| Windows operating systems supported | Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64 | | Ergonomics |
|---|
| Wall mountable | Yes | | VESA mounting | Yes | | Cable lock slot | Yes | | Panel mounting interface | 100 x 100 mm | | Tilt angle range | -5 - 90° | | Number of OSD languages | 9 | | On Screen Display (OSD) languages | Simplified Chinese, German, English, Spanish, French, Italian, Japanese, Portuguese, Russian | | Plug and Play | Yes | | Power |
|---|
| Power supply type | AC | | AC input voltage | 100-240 V | | AC input frequency | 50 - 60 Hz | | Power consumption (typical) | 26 W | | Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 40 °C | | Storage temperature (T-T) | -20 - 60 °C | | Operating relative humidity (H-H) | 20 - 80% | | Storage relative humidity (H-H) | 10 - 90% | | Packaging content |
|---|
| Quick start guide | Yes | | Cables included | AC, Audio (3.5mm), DVI, USB, VGA | | Weight & dimensions |
|---|
| Width (without stand) | 56.1 cm | | Width (with stand) | 561 mm | | Depth (with stand) | 379 mm | | Height (with stand) | 254 mm | | Weight (with stand) | 6.3 kg | | Packaging data |
|---|
| Quick start guide | Yes | | Cables included | AC, Audio (3.5mm), DVI, USB, VGA | | Logistics data |
|---|
| Harmonized System (HS) code | 85285210 | | Other features |
|---|
| Width (without stand) | 56.1 cm | | Quick start guide | Yes | | HDMI | Yes | | Power supply type | AC | | USB 2.0 ports quantity | 5 | | Display | IPS | | Dimensions (W x D x H) with stand | 561 x 379 x 254 mm | | Touchscreen | Yes | | Number of simultaneous touchpoints | 10 | | Full HD | Yes | | Energy efficiency class (old) | B | | Certificates |
|---|
| Certification | CE, TÜV-Bauart, VCCI, PSE, CU |
|
