£92.37 £76.97

Intel Pentium Gold G7400 processor 6 MB Smart Cache Box

£92.38 £76.98
In stock
SKU

BX80715G7400

Need help ordering? Call 0208 200 2000

Boxed Intel® Pentium® Gold G7400 Processor (6M Cache, 3.70 GHz) FC-LGA16A


Intel® Deep Learning Boost (Intel® DL Boost)
A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.

Intel® Optane™ Memory Supported
Intel® Optane™ memory is a revolutionary new class of non-volatile memory that sits in between system memory and storage to accelerate system performance and responsiveness. When combined with the Intel® Rapid Storage Technology Driver, it seamlessly manages multiple tiers of storage while presenting one virtual drive to the OS, ensuring that data frequently used resides on the fastest tier of storage. Intel® Optane™ memory requires specific hardware and software configuration.

Intel® Speed Shift Technology
Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.

Intel® Virtualization Technology (VT-x)
Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.

Intel® Hyper-Threading Technology
Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.

Intel® Virtualization Technology for Directed I/O (VT-d)
Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.

Intel® Virtualization Technology for Directed I/O (VT-d)
Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.

Intel® VT-x with Extended Page Tables (EPT)
Intel® VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel® Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management.

Intel® 64
Intel® 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software. Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.

Idle States
Idle States (C-states) are used to save power when the processor is idle. C0 is the operational state, meaning that the CPU is doing useful work. C1 is the first idle state, C2 the second, and so on, where more power saving actions are taken for numerically higher C-states.

Enhanced Intel SpeedStep® Technology
Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.

Thermal Monitoring Technologies
Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. An on-die Digital Thermal Sensor (DTS) detects the core's temperature, and the thermal management features reduce package power consumption and thereby temperature when required in order to remain within normal operating limits.

Intel® Volume Management Device (VMD)
Intel® Volume Management Device (VMD) provides a common, robust method of hot plug and LED management for NVMe-based solid state drives.

Intel® AES New Instructions
Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.

Secure Key
Intel® Secure Key consists of a digital random number generator that creates truly random numbers to strengthen encryption algorithms.

Execute Disable Bit
Execute Disable Bit is a hardware-based security feature that can reduce exposure to viruses and malicious-code attacks and prevent harmful software from executing and propagating on the server or network.

Intel® Boot Guard
Intel® Device Protection Technology with Boot Guard helps protect the system’s pre-OS environment from viruses and malicious software attacks.

Mode-based Execute Control (MBE)
Mode-based Execute Control can more reliably verify and enforce the integrity of kernel level code.

Intel® Control-Flow Enforcement Technology
CET - Intel Control-flow Enforcement Technology (CET) helps protect against the misuse of legitimate code snippets through return-oriented programming (ROP) control-flow hijacking attacks.
More Information
SKU BX80715G7400
EAN 5032037238410
Specification
Processor
Processor manufacturerIntel
Processor codenameAlder Lake
Memory bandwidth supported by processor (max)76.8 GB/s
Processor cache6 MB
Processor modelG7400
Processor threads4
Processor operating modes64-bit
SteppingH0
Bus typeDMI4
Processor familyIntel® Pentium® Gold
Processor cores2
BoxYes
Processor socketLGA 1700
Processor cache typeSmart Cache
Performance cores2
Performance-core base frequency3.7 GHz
Processor base power46 W
Maximum number of DMI lanes8
Memory
Maximum internal memory supported by processor128 GB
Memory types supported by processorDDR4-SDRAM, DDR5-SDRAM
Memory bandwidth supported by processor (max)76.8 GB/s
Memory channelsDual-channel
Memory bandwidth (max)76.8 GB/s
Graphics
Discrete graphics cardNo
On-board graphics card outputs supportedEmbedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
On-board graphics card maximum resolution (DisplayPort)7680 x 4320 pixels
Number of execution units16
On-board graphics card ID0x4693
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)5120 x 3200 pixels
On-board graphics card refresh rate at maximum resolution (HDMI)60 Hz
On-board graphics card refresh rate at maximum resolution (DisplayPort)60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)120 Hz
Number of displays supported (on-board graphics)4
On-board graphics card maximum resolution (HDMI)4096 x 2160 pixels
On-board graphics card DirectX version12.0
On-board graphics card OpenGL version4.5
On-board graphics card modelIntel UHD Graphics 710
On-board graphics cardYes
On-board graphics card dynamic frequency (max)1350 MHz
On-board graphics card base frequency300 MHz
Discrete graphics card modelNot available
Multi-Format Codec Engines1
Technical details
Intel® Secure KeyYes
Thermal Monitoring TechnologiesYes
Intel® Turbo Boost TechnologyNo
Intel® Quick Sync Video TechnologyYes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Intel® AES New Instructions (Intel® AES-NI)Yes
Idle StatesYes
Execute Disable BitYes
Enhanced Intel SpeedStep TechnologyYes
PCI Express slots version5.0, 4.0
PCI Express configurations1x16+1x4, 2x8+1x4
Supported instruction setsSSE4.1, SSE4.2, AVX 2.0
Scalability1S
Intel VT-x with Extended Page Tables (EPT)Yes
Embedded options availableNo
CPU configuration (max)1
Graphics outputeDP 1.4b, DP 1.4a, HDMI 2.1
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel 64Yes
StatusLaunched
Market segmentDesktop
Launch dateQ1'22
Intel Virtualization Technology (VT-x)Yes
Processor cache typeSmart Cache
OpenCL version2.1
Features
On-board graphics card ID0x4693
Maximum number of PCI Express lanes20
Processor package size45 x 37.5 mm
Thermal Monitoring TechnologiesYes
Idle StatesYes
Execute Disable BitYes
PCI Express slots version5.0, 4.0
PCI Express configurations1x16+1x4, 2x8+1x4
Supported instruction setsSSE4.1, SSE4.2, AVX 2.0
Scalability1S
Embedded options availableNo
CPU configuration (max)1
Market segmentDesktop
Harmonized System (HS) code85423119
Export Control Classification Number (ECCN)5A992CN3
Commodity Classification Automated Tracking System (CCATS)G167599
Use conditionsPC/Client/Tablet
Direct Media Interface (DMI) Revision4.0
Processor special features
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel 64Yes
Intel Turbo Boost Max Technology 3.0No
Intel® Speed Shift TechnologyYes
Intel® Optane™ Memory ReadyYes
Intel® OS GuardYes
Intel® Secure KeyYes
Intel® Turbo Boost TechnologyNo
Intel® Quick Sync Video TechnologyYes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Intel® AES New Instructions (Intel® AES-NI)Yes
Enhanced Intel SpeedStep TechnologyYes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel® Boot GuardYes
Intel® Volume Management Device (VMD)Yes
Intel® Deep Learning Boost (Intel® DL Boost)Yes
Mode-based Execute Control (MBE)Yes
Intel® Control-flow Enforcement Technology (CET)Yes
Intel® Thread DirectorNo
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0Yes
Intel® Standard Manageability (ISM)Yes
Operational conditions
Tjunction100 °C
Packaging data
Package typeRetail box
Weight & dimensions
Processor package size45 x 37.5 mm
Other features
Maximum internal memory128 GB
CPU configuration (max)1
Graphics outputeDP 1.4b, DP 1.4a, HDMI 2.1
Manufacturer Intel
In Stock Y
