£43.66 £36.38

Lenovo 7ZT7A00534 network card Internal Ethernet 1000 Mbit/s

£43.67 £36.39
Out of stock
SKU

7ZT7A00534

ThinkSystem I350-T2 PCIe 1Gb 2-Port RJ45 Ethernet Adapter
The Intel X710 family of 10 Gigabit Ethernet (GbE) server network adapters addresses the demanding needs of the next-generation data center. By providing unmatched features for server and network virtualization, small packet performance, and low power; the data center network is flexible, scalable, and resilient. The X710 is available in three host connections: a standard PCIe host interface, a Mezzanine LOM (ML2) host interface for ThinkSystem and System x servers, and an AnyFabric host interface for ThinkServer systems.
More Information
SKU 7ZT7A00534
EAN 0889488433773
Specification
Ports & interfaces
InternalYes
Ethernet LAN (RJ-45) ports2
InterfaceEthernet
Host interfacePCI Express
Connectivity technologyWired
Bandwidth
Maximum data transfer rate1000 Mbit/s
Technical details
Product colourGreen, Silver
Wake-on-LAN readyYes
Receive Side Scaling (RSS)Yes
Intelligent OffloadsYes
Intel® Virtualization Technology (Intel® VT)Yes
Intel Virtual Machine Device Queues (VMDq)Yes
Intel Data Direct I/O TechnologyYes
Harmonized System (HS) code85176990
Network
VLAN taggingYes
Jumbo frames9500
iSCSI supportYes
Networking standardsIEEE 802.1Q, IEEE 802.1ad, IEEE 802.1as, IEEE 802.1p, IEEE 802.3ae, IEEE 802.3x
Wake-on-LAN readyYes
Jumbo frames supportYes
Maximum data transfer rate1000 Mbit/s
Flow control supportYes
Design
Product colourGreen, Silver
CertificationEN55022 EN55024 EN 61000-3-2 EN 61000-3-3 ICES-003, Issue-004 FCC 47 CFR Part 15 Class A VCCI AS/NZS CISPR 22 / C-tick RRL for KC BSMI UL 94 V-1
InternalYes
Component forServer
System requirements
Compatible operating systemsMicrosoft Windows Server 2008 R2 Microsoft Windows Server 2012 Microsoft Windows Server 2012 R2 Microsoft Windows Server 2016 Red Hat Enterprise Linux 6 Server x64 Edition Red Hat Enterprise Linux 7 SUSE Linux Enterprise Server 11 for AMD64/EM64T SUSE Linux Enterprise Server 11 with Xen for AMD64/EM64T SUSE Linux Enterprise Server 12 SUSE Linux Enterprise Server 12 with XEN VMware vSphere 5.5 (ESXi) VMware vSphere 6.0 (ESXi) VMware vSphere 6.5 (ESXi)
Operational conditions
Operating temperature (T-T)0 - 55 °C
Storage temperature (T-T)-20 - 65 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)5 - 80%
Operating altitude0 - 2134 m
Packaging data
Quantity1
Performance
Wake-on-LAN readyYes
Receive Side Scaling (RSS)Yes
Intelligent OffloadsYes
Intel® Virtualization Technology (Intel® VT)Yes
Intel Virtual Machine Device Queues (VMDq)Yes
Intel Data Direct I/O TechnologyYes
Certificates
CertificationEN55022 EN55024 EN 61000-3-2 EN 61000-3-3 ICES-003, Issue-004 FCC 47 CFR Part 15 Class A VCCI AS/NZS CISPR 22 / C-tick RRL for KC BSMI UL 94 V-1
Other features
Compatible operating systemsMicrosoft Windows Server 2008 R2 Microsoft Windows Server 2012 Microsoft Windows Server 2012 R2 Microsoft Windows Server 2016 Red Hat Enterprise Linux 6 Server x64 Edition Red Hat Enterprise Linux 7 SUSE Linux Enterprise Server 11 for AMD64/EM64T SUSE Linux Enterprise Server 11 with Xen for AMD64/EM64T SUSE Linux Enterprise Server 12 SUSE Linux Enterprise Server 12 with XEN VMware vSphere 5.5 (ESXi) VMware vSphere 6.0 (ESXi) VMware vSphere 6.5 (ESXi)
Jumbo frames9500
Receive Side Scaling (RSS)Yes
Intelligent OffloadsYes
Intel® Virtualization Technology (Intel® VT)Yes
Intel Virtual Machine Device Queues (VMDq)Yes
Intel Data Direct I/O TechnologyYes
Flow control supportYes
Harmonized System (HS) code85176990
Packaging content
Quantity1
Manufacturer Lenovo
In Stock N
