£1688.00 £1406.67

Lenovo ThinkSystem SR650 server Rack (2U) Intel Xeon Silver 2.4 GHz 32 GB DDR4-SDRAM 750 W

£1,688.00 £1,406.67
Out of stock
SKU

7X06A0P0EA

Intel Xeon Silver 4210R (13.75MB Cache, 2.4GHz), 32GB DDR4-SDRAM (2933MHz), Matrox G200e, LAN, 9350-8i, 750W


Future defined data center
Lenovo delivers cost-effective, reliable, and scalable solutions by combining industry-leading technology and the world’s best software-defined offerings with Lenovo ThinkShield, XClarity, and TruScale Infrastructure Services to manage the life cycle of your data center needs. ThinkSystem SR650 provides support for data analytics, hybrid cloud, hyperconverged infrastructure, video surveillance, high performance computing and much more.

Workload-optimized support
Intel® Optane™ DC Persistent Memory delivers a new, flexible tier of memory designed specifically for data center workloads that offer an unprecedented combination of high capacity, affordability, and persistence. This technology will have a significant impact on real-world data center operations: reduction of restart times from minutes down to seconds, 1.2x virtual machine density, dramatically improved data replication with 14x lower latency and 14x higher IOPS, and greater security for persistent data built into hardware.* * Based on Intel internal testing, August 2018.

Flexible storage
Lenovo AnyBay design features a choice of drive interface type in the same drive bay: SAS drives, SATA drives, or U.2 NVMe PCIe drives. Freedom to configure some of the bays with PCIe SSDs and still use the remaining bays for capacity SAS drives provides the ability to upgrade to more PCIe SSDs in the future as needed.

Empowering IT management
Lenovo XClarity Controller is the embedded management engine in all ThinkSystem servers that is designed to standardize, simplify, and automate foundation server management tasks. Lenovo XClarity Administrator is a virtualized application that centrally manages ThinkSystem servers, storage, and networking, which can reduce provisioning time up to 95% versus manual operation. Running XClarity Integrator helps you streamline IT management, speed provisioning, and contain costs by seamlessly integrating XClarity into an existing IT environment.
More Information
SKU 7X06A0P0EA
EAN 0889488661473
Specification
Processor
Processor generation2nd Generation Intel® Xeon® Scalable
Execute Disable BitYes
Embedded options availableYes
Processor cache13.75 MB
Processor frequency2.4 GHz
Processor boost frequency3.2 GHz
Number of processors installed1
Processor model4210R
Processor manufacturerIntel
Motherboard chipsetIntel® C624
Processor familyIntel Xeon Silver
Memory
Internal memory32 GB
Memory layout (slots x size)1 x 32 GB
Memory clock speed2933 MHz
Internal memory typeDDR4-SDRAM
Storage
Supported RAID controllers9350-8i
RAID supportYes
RAID levels0, 1, 5, 6, 10, 50, 60
Optical drive typeNo
Graphics
On-board graphics card modelMatrox G200e
Maximum graphics card memory16 MB
On-board graphics cardYes
Network
Ethernet LANYes
Cabling technology10/100/1000Base-T(X)
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
VGA (D-Sub) ports quantity1
USB 2.0 ports quantity1
Optical drive
Optical drive typeNo
Design
Redundant fans supportYes
Rack railsYes
Rack mountingYes
Optical drive typeNo
Chassis typeRack (2U)
Product colourBlack, Metallic
Performance
Compatible operating systemsMicrosoft Windows Server 2016 Microsoft Windows Server 2012 R2 Red Hat Enterprise Linux 7.4 Red Hat Enterprise Linux 7.3 Red Hat Enterprise Linux 6.9 Server x64 Edition SUSE Linux Enterprise Server 12 SP3 SUSE Linux Enterprise Server 12 SP2 SUSE Linux Enterprise Server 11 for AMD64/EM64TSP4 VMware vSphere 6.5 (ESXi) Update 1 VMware vSphere 6.5 (ESXi) VMware vSphere 6.0 (ESXi) Update 3
Performance managementXClarity Enterprise
Trusted Platform Module (TPM)Yes
Harmonized System (HS) code84714100
Software
Compatible operating systemsMicrosoft Windows Server 2016 Microsoft Windows Server 2012 R2 Red Hat Enterprise Linux 7.4 Red Hat Enterprise Linux 7.3 Red Hat Enterprise Linux 6.9 Server x64 Edition SUSE Linux Enterprise Server 12 SP3 SUSE Linux Enterprise Server 12 SP2 SUSE Linux Enterprise Server 11 for AMD64/EM64TSP4 VMware vSphere 6.5 (ESXi) Update 1 VMware vSphere 6.5 (ESXi) VMware vSphere 6.0 (ESXi) Update 3
Processor special features
Enhanced Intel SpeedStep TechnologyYes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Trusted Execution TechnologyYes
Intel 64Yes
Intel Virtualization Technology (VT-x)Yes
Power
Number of redundant power supplies installed1
Redundant power supply (RPS) supportYes
Power supply input frequency50 - 60 Hz
Power supply750 W
Operational conditions
Storage temperature (T-T)-40 - 60 °C
Operating relative humidity (H-H)8 - 90%
Storage relative humidity (H-H)8 - 90%
Operating temperature (T-T)5 - 45 °C
Operating altitude0 - 3050 m
Technical details
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Trusted Platform Module (TPM)Yes
Redundant fans supportYes
Rack railsYes
Rack mountingYes
Chassis typeRack (2U)
Management features
Performance managementXClarity Enterprise
Weight & dimensions
Width445 mm
Height87 mm
Depth764 mm
Manufacturer Lenovo
In Stock N
