£231.48 £192.89

StarTech.com Triple Monitor 4K USB-C Dock with 5x USB 3.0 Ports

£231.48 £192.90
In stock
SKU

DK30CH2DPPDU

Need help ordering? Call 0208 200 2000

StarTech.com 4K USB C Dock - 60W Power Delivery - Triple Monitor USB C to HDMI DisplayPort Docking Station (DK30CH2DPPDU)
Laptop Docking Station | Mac & Windows® | 60W Power Delivery| 4K 60 DP + HDMIThis TAA compliant 4K USB-C™ dock for Mac and Windows® laptops takes productivity to a whole new level, with support for triple 4K monitors - a first in the market. The USB Type-C dock provides 60W charging power, and 5x USB 3.0 ports to connect your peripheral devices. It's the perfect accessory for your Dell™ XPS 15, Chromebook Pixel™; or another USB-C enabled PC laptop.The dock also connects to USB 3.0 laptops with a USB-A port (using a USB-C to A cable such as the USB315AC1M, sold separately).Note: Power Delivery to charge your laptop is not available through USB-A, and only dual display is supported.Enhance ProductivityThe 4K USB-C Dock for Mac and Windows lets you create a three-monitor Ultra HD workstation. Connect:• 2x 4K DisplayPort (DisplayLink) at 4096 x 2160 resolution / 3840 x 2160 @ 60Hz and• 1x 4K HDMI (DP Alt Mode) at 4096 x 2160 resolution @ 24Hz / 3840 x 2160 @ 30HzFor high-resolution applications, the universal laptop docking station can also connect to a 5K display (5120 x 2880 resolution) at 60Hz, by connecting the two DisplayPort ports to a single 5K display.Powerful ConnectionsThis triple-monitor docking station lets you connect your peripherals to transform your laptop into a full-sized workstation. With five USB 3.0 ports (1x USB Type-C and 4x USB Type-A incl 1x Fast-Charge port), a Gigabit Ethernet port, headset jack and separate 3.5 mm audio and microphone ports, you have all the connections you need for maximum performance.60W Power DeliveryUsing a single cable, the USB-C docking station with Power Delivery (up to 60W) will power and charge your laptop, and power your peripherals with its 120W power adapter.The DK30CH2DPPDU is backed by a StarTech.com 3-year warranty and free lifetime technical support.The StarTech.com Advantage
More Information
SKU DK30CH2DPPDU
EAN 0065030871143
Specification
Ports & interfaces
Combo headphone/mic portYes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity2
Number of microphone inputs1
Headphone connectivity3.5 mm
Host interfaceUSB 3.2 Gen 1 (3.1 Gen 1) Type-C
Ethernet LAN (RJ-45) ports1
HDMI ports quantity1
DisplayPorts quantity2
Microphone inYes
Headphone outputs1
Connectivity technologyWired
Network
Full duplexYes
Auto MDI/MDI-XYes
Networking standardsIEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s
Ethernet LAN (RJ-45) ports1
Performance
UASP supportYes
Maximum digital resolution4096 x 2160 pixels
Full duplexYes
Auto MDI/MDI-XYes
On/off switchYes
Product colourBlack, Silver
Card reader integratedNo
Brand compatibilityAny brand
Cable lock slotYes
Data transfer rate6 Gbit/s
CertificationCE, FCC, TAA
Technical details
Product colourBlack, Silver
Brand compatibilityAny brand
Cable lock slotYes
Data transfer rate6 Gbit/s
Sustainability certificatesRoHS
Harmonized System (HS) code84733020
Products per master (outer) case10 pc(s)
Master (outer) case width318 mm
Master (outer) case length370 mm
Master (outer) case height382 mm
Storage
Card reader integratedNo
Power
Input current2 A
Compatible power plug typesEU, UK
AC input voltage100 - 240 V
Output voltage20 V
Output current6 A
Power supply60 W
Software
Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Mac operating systems supportedMac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina
Mac compatibilityYes
Other operating systems supportedChrome
Operational conditions
Operating temperature (T-T)0 - 60 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 95%
Sustainability
Sustainability certificatesRoHS
Weight & dimensions
Weight385 g
Width82 mm
Depth270 mm
Height34 mm
Package weight1.45 kg
Package width161 mm
Package depth296 mm
Package height71 mm
Design
Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Mac operating systems supportedMac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina
Product colourBlack, Silver
Cable lock slotYes
CertificationCE, FCC, TAA
Packaging data
Package weight1.45 kg
Package width161 mm
Package depth296 mm
Package height71 mm
Packaging content
ManualYes
Cables includedUSB Type-C
AC adapter includedYes
Certificates
CertificationCE, FCC, TAA
Logistics data
Products per master (outer) case10 pc(s)
Master (outer) case width318 mm
Master (outer) case length370 mm
Master (outer) case height382 mm
Other features
Number of microphone inputs1
ChipsetDisplayLink - DL-6950, Genesys Logic - GL3523, Texas Instruments - TPS65982, Parade Technologies - PS176
