| Specification |
| Ports & interfaces |
|---|
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-C | | USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 | | USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 | | HDMI ports quantity | 1 | | Hub interfaces | HDMI, RJ-45, USB 3.2 Gen 1 (3.1 Gen 1) Type-A, USB 3.2 Gen 1 (3.1 Gen 1) Type-C | | Ports quantity | 4 | | Maximum resolution (HDMI) | 3840 x 2160 pixels | | HDMI version | 2.0b | | Cable length | 0.3 m | | Features |
|---|
| Product colour | Black, Grey | | Cable length | 0.3 m | | Data transfer rate | 5000 Mbit/s | | Maximum resolution (HDMI) | 3840 x 2160 pixels | | USB Power Delivery | Yes | | USB Power Delivery revision | 3.0 | | Housing material | Plastic | | USB Power Delivery up to | 100 W | | HD type | 4K Ultra HD | | Number of displays supported | 1 | | Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-C | | Network |
|---|
| Full duplex | Yes | | Auto MDI/MDI-X | Yes | | UASP support | Yes | | Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u | | Ethernet LAN data rates | 10,100,1000,2000 Mbit/s | | Data transmission |
|---|
| Data transfer rate | 5000 Mbit/s | | Technical details |
|---|
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u | | Product colour | Black, Grey | | Sustainability certificates | CE, RoHS | | Performance |
|---|
| Full duplex | Yes | | Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u | | Data transfer rate | 5000 Mbit/s | | USB Power Delivery | Yes | | USB Power Delivery revision | 3.0 | | Harmonized System (HS) code | 84719000 | | System requirements |
|---|
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 | | Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur | | Other operating systems supported | Chrome | | Packaging data |
|---|
| Package width | 174 mm | | Package depth | 142 mm | | Package height | 32 mm | | Package weight | 126 g | | Design |
|---|
| Product colour | Black, Grey | | Cable length | 0.3 m | | Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 45 °C | | Storage temperature (T-T) | -10 - 70 °C | | Operating relative humidity (H-H) | 10 - 90% | | Sustainability |
|---|
| Sustainability certificates | CE, RoHS | | Logistics data |
|---|
| Master (outer) case width | 340 mm | | Master (outer) case length | 535 mm | | Master (outer) case height | 315 mm | | Products per master (outer) case | 30 pc(s) | | Weight & dimensions |
|---|
| Package width | 174 mm | | Package depth | 142 mm | | Package height | 32 mm | | Package weight | 126 g | | Other features |
|---|
| Mac compatibility | Yes |
|
