Ports & interfaces |
---|
Internal | Yes |
Ethernet LAN (RJ-45) ports | 1 |
Interface | Ethernet |
Host interface | PCI Express |
Connectivity technology | Wired |
Bandwidth |
---|
Full duplex | Yes |
Maximum data transfer rate | 2000 Mbit/s |
Antenna |
---|
Quality of Service (QoS) support | Yes |
Technical details |
---|
Quality of Service (QoS) support | Yes |
Product colour | Green, Grey |
Wake-on-LAN ready | Yes |
Harmonized System (HS) code | 85176990 |
Sustainability compliance | Yes |
Sustainability certificates | CE, RoHS |
Network |
---|
VLAN tagging | Yes |
Ethernet interface type | Gigabit Ethernet |
Quality of Service (QoS) support | Yes |
Ethernet LAN | Yes |
Cabling technology | 10/100/1000BaseT(X) |
Networking standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
Wake-on-LAN ready | Yes |
Maximum operating distance | 100 m |
Full duplex | Yes |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Maximum data transfer rate | 2000 Mbit/s |
Flow control support | Yes |
Design |
---|
Product colour | Green, Grey |
Certification | FCC, BSMI, VCCI |
Internal | Yes |
LED indicators | Status |
Component for | PC |
Software |
---|
Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows 8.1 |
Linux operating systems supported | Yes |
Indication |
---|
LED indicators | Status |
System requirements |
---|
Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows 8.1 |
Linux operating systems supported | Yes |
Operational conditions |
---|
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -40 - 70 °C |
Operating relative humidity (H-H) | 10 - 90% |
Storage relative humidity (H-H) | 5 - 90% |
Sustainability |
---|
Sustainability compliance | Yes |
Sustainability certificates | CE, RoHS |
Weight & dimensions |
---|
Width | 78.5 mm |
Depth | 120.8 mm |
Height | 21.5 mm |
Packaging content |
---|
Mounting brackets included | Yes |
Quick installation guide | Yes |
Resource CD | Yes |
Performance |
---|
Wake-on-LAN ready | Yes |
Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows 8.1 |
Linux operating systems supported | Yes |
Packaging data |
---|
Mounting brackets included | Yes |
Quick installation guide | Yes |
Certificates |
---|
Certification | FCC, BSMI, VCCI |
Other features |
---|
Flow control support | Yes |
Harmonized System (HS) code | 85176990 |
